Brake cylinders Tilton

Description

Main cylinders in the 76 series incorporate new features, such as the added exhaust port at the top, for universal appeal. The 76-series master cylinders retain the rear port to continue to match the function of the old version, while the added extra-deep upper port allows the use of a banjo fitting. Addition of an AN-3 exhaust port at the top (along with the original exhaust port at the rear) provides more flexibility. Optional use of both ports to connect to a brake pressure sensor, bleed port, brake light switch and more. The upper exhaust port is compatible with both AN-3 and banjo fittings. Both exhaust ports can now be used with standard fittings without the need for modifications or adapters. A lighter, more compact body design provides additional clearance. Available in seven bore sizes (see P/N options above). 5/16"-24 push bar
